Input
• Redundant power inputs:
Terminal Block: 52 - 57VDC

Power Consumption
• Device: Max. 20W (without PoE)

PoE Power Output
• PoE can be configured as:
1. 6-port 15.4 W PoE and 2- port 60 watt PoE
2. 8-port 30W PoE
3. 4-port 10/100/1000 TX and 4-port 60 watt PoE
4. Other PoE power level configuration can be done through firmware

• PoE power budget: 240W

Protection
• Reverse polarity protection

Operating Temperature
• -40°C to 75°C (-40°F to 167°F)
Tested @ -40°C to 85°C (-40°F to 185°F)

Storage Temperature
• -40°C to 85°C (-40°F to 185°F)

Ambient Relative Humidity
• 5% to 95% (non-condensing)

IEC60068-2-6 Fc (Vibration)
IEC60068-2-27 Ea (Shock)
IEC60068-2-32 Ed (Free fall)

ISO
• Manufactured in an ISO9001 facility

EMI
FCC Part 15B, Class A
EN61000-6-4
EN55022
EN61000-3-2
EN61000-3-3

EMS
EN61000-6-2
• EN61000-4-2 (ESD Standards)
• EN61000-4-3 (Radiated RFI Standards)
• EN61000-4-4 (Burst Standards)
• EN61000-4-5 (Surge Standards)
• EN61000-4-6 (Induced RFI Standards)
• EN61000-4-8 (Magnetic Field Standards)
